    Vitex Decking

    Maintenance and Installation Guidelines

    Introduction

    Proper installation, care and maintenance will ensure you get the best performance from your deck. These recommendations should be read in conjunction with NZS3602, NZS3604, NZS3605, NZS3640, NZS4203 and BRANZ Bulletin 489 and any relevant Territorial Authority requirements.

    Storage and Handling

    Vitex decking should be kept dry and out of the weather until installation. On site each pack should be kept off the ground by at least 100mm by placing it on bearers and covered to protect from sun and rain.

    Installation

    Ventilation
    Free air circulation under the decking is very important to help minimise cupping and warping for any timber. Proper ventilation ensures the potential difference in moisture levels between top face and the underside of the boards is reduced and extends the life and performance of the deck. The sub deck should have at least 450mm clearance from the ground and should also have adequate drainage. This, in conjunction with suitable spacing, will allow for adequate ventilation. NB: It is important that the perimeter of the deck is not fully enclosed by a surround, and remains open to airflow. Completely enclosing the sides of the deck will inhibit proper ventilation and compromise the performance of the decking. In wet areas or over water, additional clearance is recommended. Failure to provide for suitable ventilation is a major cause of early decking failure. Other steps that can be taken to minimise moisture differential are:

    A. A ground level vapour barrier (with slit drainage).

    B. A suitable surface coating on all four sides of the decking boards (refer coating section).




    Span
    Vitex Decking 19mm thick should be installed at maximum 450mm joist centres. For 32mm thick decking this can be increased up to 600mm joist centres. Given that Radiata pine joists are softwood and Vitex is a strong hardwood, the joists should be clean and sound and the screws should penetrate at least 40mm into the joists to achieve good holding. Pre-drilling and counter-sinking is essential to avoid end splits.

    End Sealing
    Vitex Decking 19mm thick should be installed at maximum 450mm joist centres. For 32mm thick decking this can be increased up to 600mm joist centres. Given that Radiata pine joists are softwood and Vitex is a strong hardwood, the joists should be clean and sound and the screws should penetrate at least 40mm into the joists to achieve good holding. Pre-drilling and counter-sinking is essential to avoid end splits.

    Coating
    In order to minimise surface checking, cupping and discolouration it is recommended Vitex decking be coated on all four sides prior to being laid. This will slow moisture transference into and out of the wood, thus maintaining more even moisture content through the piece. Proper coatings can vastly decrease the maintenance required on your decking. NB: Boards should be free of all surface marks and stains before coating. It is recommended that a “clear” decking oil is used.

    Spacing
    In average New Zealand climatic conditions, Kiln Dried (KD) decking will expand slightly. KD (i.e. under 18% moisture content) decking will need extra spacing or gaps, to allow for expansion as the decking takes in ambient moisture. If laid too closely the deck will swell and possibly lift off the joists. In average New Zealand climatic conditions 90x19mm KD decking should be spaced 4mm apart. 140x19mm decking should be spaced 6mm apart. The specified gap for each size will allow the deck to drain and allow air circulation under and around the decking. NB: These are recommendations only. An allowance for regional climate conditions should also be factored in.

    Fastening
    Screws are essential for 140x19mm decking. We recommend 10g 65mm stainless steel (T316) screws through the pre-drilled and countersunk face of each board, two per joist 20 mm from the ends and edges. Care should be taken not to over-drive screws. For 90x19mm decking screws are also recommended (see PlaceMakers Fastening Catalogue for full range). However, if you chose nails they should be of sufficient length (60mm), stainless steel (T316) with annular grooves.

    Maintenance

    Cleaning & Washing
    Hardwood decks should be cleaned with a stiff brush at least once a year to clear gaps and remove surface mould which can be a slip hazard in wet weather. It is also important for the life of the deck to keep it clear of leaf litter, place pot plants or other large objects on raised “feet” to allow the decking under them to dry out. Hardwood decking can be water-blasted BUT it is important to do so at a low pressure so as not to damage the fibres of the board by going too hard and/or too close. Care must be taken not to stop at the end of the stroke but to lift the nozzle away when changing direction. Washing/brushing the deck down with a mild solution of Janola and water (1:16), or suitable equivalent, will remove any build-up of resin or extractives that may leach out of the timber as the pieces “season” in situ. There are also various chemical cleaning agents available, from detergents through to acids. Follow manufacturer’s instructions and be conscious of the run off. The amount of run off will depend on the specie, how dry it is before the decking is laid and how exposed the deck is to the weather.

    Re-coating

    Always follow the manufacturer’s specification for re-coating.

    Disclaimer
    Hardwood Decking is manufactured with care and inspected to ensure quality, but it is a natural wood product and subject to variations in weight, density, colour, grain and performance. Care must be taken at installation and maintenance to allow for movement. Some swelling, shrinkage, movement and checking are normal occurrences in timber decking.

    The material in these guidelines were taken from guidelines supplied by Rosenfeld Kidson and JSC timber. PlaceMakers takes no responsibility for there accuracy or for any damage caused directly or indirectly through there use.

    Budget test Care Durability Sustainability Aesthetic Maintenance Treatment Ease of Build Profiles
    Merch Radiata Pine Budget Friendly Pine requires ongoing cleaning and staining to maintain the product look and feel. Once a year minium though every 6 months is better Lifespan of around 25 years if cared for correctly. Is susceptible to wear and tear in hotter climates. Locally sourced product May include some defects (no more than 1/3rd of the cross section along the length of the board) Perform recommended care every 6-12 months to ensure product lifespan. Clean the deck (with either warm soapy water or a deck cleaner solution). A pressure washer is best for washing down but don't overdo it! Once dry, apply decking stain or oil as required CCA (Copper Chrome Arsenic) wood preservative Standard Building Product, ideal for cooler climates to avoid bending or cracking Smooth & Grip Tread
    Premium Radiata Pine Low investment Pine requires ongoing cleaning and staining to maintain the product look and feel. Once a year minium though every 6 months is better Lifespan of around 25 years if cared for correctly. Is susceptible to wear and tear in hotter climates. Locally sourced product Only small round defects may be present but must not detract from the premium class finish of the deck appearance. Perform recommended care every 6-12 months to ensure product lifespan. Clean the deck (with either warm soapy water or a deck cleaner solution). A pressure washer is best for washing down but don't overdo it! Once dry, apply decking stain or oil as required CCA (Copper Chrome Arsenic) wood preservative Standard Building Product, ideal for cooler climates to avoid bending or cracking Smooth & Grip Tread
    Modified Radiata Pine Low-Medium Investment Modified Pine requires ongoing cleaning to maintain the look and feel. Lifespan of around 25 years, less susceptible to wear and tear than Pine Decking. Locally sourced product Pre-stained Every year to ensure product lifespan. Chemically treated to be harder and more resistant that standard pine. Reduces the risk of bending in warmer temperatures. Standard building material Smooth or Grip Tread (depending on brand)
    Hardwood Medium-High Investment Hardwood requires ongoing cleaning to maintain the look and feel. Lifespan of up to 50 years depending on species and if properly maintained FSC(R) certified - excludes Vitex which is community produced from the Solomon Islands High aesthetic. Some fading will occur over time. Kwila has a tencency to bleed and should not be used over vegetable gardens. Requires cleaning every year using a light detergent with anti-fungal agent.. Oiling is recomended however is optional based on the desired aesthetic. Pre-stained & chemical free Read User Guide for information on how to best install this decking. Smooth or Grip Tread (depending on species)
    Composite Quality Investment Sweep or mop with warm water as required Very high durability, long lifespan. 10- 50years fade and stain warranty included (depending on brand) Uses recycled wood fibre and plastics to create the composite timber. High aesthetic, will hold look and feel consistently as it ages. Very Low Maintenance to preserve product look and feel. Pre-finished in colour. Conatinus fungicide Easy to cut and install. Refer to User Guide on how best to instal lthis decking. Smooth or Grip Tread (depending on brand)

    Decking Guides

    Learn about the differences with maintenance and installation of Garapa, Kwila, Radiata Pine, Purple Heart, and Vitex Decking. Plus check out our decking screw selection guide.
